PRODUCT DESCRIPTION
The ISO-BLOCO MULTI-FUNCTIONAL TAPE is a special joint sealing strip with outstanding functionality that can be used for a wide range of applications. It is used to seal connection joints of windows and doors against drafts and driving rain. At the same time it also provides thermal and acoustic properties throughout the joint.
The ISO-BLOCO MULTI-FUNCTIONAL TAPE is permeable to vapour diffusion according to the RAL principles, this guarantees that the joint will dry out completely.
Applications
The ISO-BLOCO MULTI-FUNCTIONAL TAPE is an “all-in-one tape” which combines all the requirements of the energy savings regulations (EnEV) and the RAL “installation guide” in one product. It is therfore especially suitable for the safe, as in reliable, straightforward and time saving sealing of window and door connections.
Packaging
pre-compressed rolls with self-adhesion on one side (to aid installation) Rolls are delivered in cardboard boxes.
PRODUCT ADVANTAGES
- 3-level seal with just one product
- sealing a wide range of joints with a minimum of tape dimensions
- easy one step application for a reliable seal
- significant cost advantage through time saving installation during fitting
- can be installed in adverse weather conditions
- conforms to Energy Saving Standards and the principles of the RAL “installation guide”
- weather-proof
- 10 year performance guarantee*
*On the conditions of the manufacturer (available upon request).
| Technical data | Standard | Classification |
| Material description | impregnated PUR flexible foam | |
| Impregnant | Fire esistant polymeric dispersion | |
| Colour | grey, inside coloured | |
| Air permeability coefficient | DIN EN 12114 | a ≤ 0,1 m³/[h*m*(daPa)ⁿ] |
| Impermeable to driving rain | DIN EN 1027 | ≥ 600 Pa |
| Temperature stability range | DIN 18542 | -30°C to +80°C |
| Classification according to | DIN 18542 | BG 1 ja BG R |
| UV light and weather stability | DIN 18542 | requirements fulfilled |
| Compatibility with adjacent building materials | DIN 18542 | requirements fulfilled |
| Dimension tolerance | DIN 7715 T5 P3 | requirements fulfilled |
| Building material class | DIN 4102 | B 1 (fire resistant) |
| Thermal conductivity | DIN EN 12667 | λ = 0,048 W/m*K |
| Water vapour diffusion resistance | DIN EN ISO 12572 | μ ≤ 100 |
| Steam pressure gradient | outside vapour permeable (opposite to coloured side) | |
| U-value: Window construction depth 60 mm/70 mm/80 mm | DIN 4108-3 | U = 0,8 W/m2*K; U = 0,7 W/m2*K; U = 0,6 W/m2*K |
| Shelf life | 1 year, dry and in original packing |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||
Other dimensions available on special order.
|
SEALING PERFORMANCE
Details and information presented in this document are based on the best knowledge available at the time. They are intended for general information purposes, and it is recommended that users conduct their own tests under their specific conditions to ensure the product’s suitability for its intended use. No definitive guarantee or liability can be given regarding the details or the absolute completeness of the information provided in these guidelines. We reserve the right to improve or modify technical specifications and information without prior notice.
